漫谈容器化技术（swarm篇）

01 引言

在前面的博客，关于容器化技术，我写了相关的博客，有兴趣的同学可以参阅下：

• 《漫谈容器化技术》
• 《漫谈容器化技术（docker原理篇）》
• 《漫谈容器化技术（docker使用篇）》
• 《漫谈容器化技术（docker实践篇）》

本文主要讲解的是swarm。

02 简介

Docker Swarm 是 Docker 的集群管理工具。它将 Docker 主机池转变为单个虚拟 Docker 主机。 Docker Swarm 提供了标准的 Docker API，所有任何已经与Docker守护程序通信的工具都可以使用 Swarm 轻松地扩展到多个主机。

支持的工具包括但不限于以下各项：

• Dokku
• Docker Compose
• Docker Machine
• Jenkins

03 原理

如下图所示，swarm 集群由管理节点（manager）和工作节点（work node）构成。

• swarm mananger：负责整个集群的管理工作包括集群配置、服务管理等所有跟集群有关的工作。
• work node：即图中的 available node，主要负责运行相应的服务来执行任务（task）。

04 swarm 集群部署

以下内容为实操内容，仅做参考！简单的案例可以参考：https://www.runoob.com/docker/docker-swarm.html

4.1 开启防火墙以及初始化端口

注意：每台机子都要操作！

172.16.3.0这个需要替换为实际机器的网关

ufw allow 22/tcp ;\
ufw allow from 172.16.3.0/24 to any port 4789 proto udp;\
ufw allow from 172.16.3.0/24 to any port 2377 proto tcp;\
ufw allow from 172.16.3.0/24 to any port 15389 proto tcp;\
ufw allow from 172.16.3.0/24 to any port 7946 ;\
ufw enable

4.2 安装docker 4.2.1 添加仓库

curl -fsSL https://download.docker.com/linux/ubuntu/gpg | sudo apt-key add -
add-apt-repository "deb [arch=amd64] http://mirrors.tuna.tsinghua.edu.cn/docker-ce/linux/ubuntu $(lsb_release -cs) stable"

4.2.2 安装docker

注意：每台机子都要操作！

4.2.2.1 安装docker-cli

apt update && apt install docker-ce docker-ce-cli -y

4.2.2.2 按需拷贝cert证书到对应的目录

/etc/docker/daemon.json
/etc/docker/ca.pem
/etc/docker/server-cert.pem
/etc/docker/server-key.pem

4.2.2.3 编辑systemd文件

编辑systemd文件docker.service 并保存：

vim /etc/systemd/system/multi-user.target.wants/docker.service

在ExecStart=/usr/bin/dockerd -H fd:// --containerd=/run/containerd/containerd.sock后追加

-H tcp://0.0.0.0:15389

4.2.2.4 资源限制

执行以下指令确认机器资源：

cat /proc/cpuinfo | grep processor | wc -l ; cat /proc/meminfo | grep MemTotal | awk '{printf "MEM: %.2fG\n",$2/1024/1024 }'

编辑 /etc/systemd/system/docker-limit.slice 文件添加容器资源限制CPUQuota的值设置为cpu线程数*100-25，然后加上半角百分号（MemoryMax的值为内存g数取整-0.5，MemoryHigh的值为内存g数取整-1，都以大写半角G结尾）

vim  /etc/systemd/system/docker-limit.slice

添加以下内容

[Unit]
Before=slices.target
[Slice]
CPUAccounting=true
MemoryAccounting=true
CPUQuota=375%
MemoryHigh=14G
MemoryMax=14.5G
[Install]
WantedBy=multi-user.target

4.2.2.5 拷贝文件

拷贝文件并重启服务：

cp /etc/systemd/system/multi-user.target.wants/docker.service /etc/systemd/system/docker.service && systemctl daemon-reload && systemctl enable docker && systemctl restart docker && systemctl enable docker-limit.slice && systemctl start docker-limit.slice

4.2.2.6 查看资源限制是否生效

systemctl status docker-limit.slice

预计返回：

 docker-limit.slice
     Loaded: loaded (/etc/systemd/system/docker-limit.slice; enabled; vendor preset: enabled)
     Active: active since Wed 2021-11-03 09:37:07 CST; 2 weeks 1 days ago
      Tasks: 650
     Memory: 4.9G (high: 14.0G max: 14.5G)
        CPU: 1d 9h 5min 47.297s
     CGroup: /docker.slice/docker-limit.slice
             ├─docker-3551bddf43c8d857e777a75623a03adbab7a52a52b0d0440effed70ec4cbe1ac.scope
             │ ├─456640 /bin/sh -c mkdir -p /var/log/nginx/ && chown -R nginx /var/log/nginx/ && sed -i "s/__WORKER_PROCESSES__/${NGINX_WORKER_PROCESSES:-1}/" /etc/nginx/nginx.conf &&sed -i "s/__WORKER_CO>
             │ ├─456726 nginx: master process nginx -g daemon off;
             │ └─456727 nginx: worker process
             ├─docker-47223bd402422f5377b849cdfbb61e67a94b662509df961137de1c785217af61.scope
             │ ├─3601224 /bin/sh -c mkdir -p /app/logs; if [ -d pre-exec-shells ];then for n in `ls pre-exec-shells/`;do bash pre-exec-shells/$n;done;fi;bash pre_exec.sh;mkdir -p /app/logs/${APP_VERSION}->
             │ └─3601313 /usr/lib/jvm/java-11-openjdk-amd64/bin/java -server -Xmx384m -Xms16m -XX:MetaspaceSize=32m -XX:MaxMetaspaceSize=256m -XX:OnOutOfMemoryError=kill -9 %p -XX:+UnlockExperimentalVMOpt>
             ├─docker-5a28f65f25453c7afe5d05e9151565b846f242a7b42703779d9616315bc2c099.scope
             │ ├─620135 /sbin/tini -- node server/index.js
             │ └─620292 node server/index.js
             ├─docker-65acea9543a5468ead7ae6cb61747aa194bc344a4dab7547b02406469a9bcea5.scope
             │ ├─3651833 /bin/sh -c mkdir -p /app/logs; if [ -d pre-exec-shells ];then for n in `ls pre-exec-shells/`;do bash pre-exec-shells/$n;done;fi;bash pre_exec.sh;mkdir -p /app/logs/${APP_VERSION}->
             │ └─3651926 /usr/lib/jvm/java-11-openjdk-amd64/bin/java -server -Xmx384m -Xms16m -XX:MetaspaceSize=32m -XX:MaxMetaspaceSize=256m -XX:OnOutOfMemoryError=kill -9 %p -XX:+UnlockExperimentalVMOpt>
             ├─docker-8560bf704d8183fea5eaac8ff60ecc2fd948498bcba999e7121f6909f0032515.scope
             │ ├─325697 /bin/sh -c cd /app && if [ -d pre-exec-shells ];then for n in `ls pre-exec-shells/`;do bash pre-exec-shells/$n;done;fi;npm run start:demonstrate
             │ ├─325782 npm
             │ ├─325832 sh -c cross-env NODE_ENV=demonstrate nuxt start
             │ ├─325833 node /app/node_modules/.bin/cross-env NODE_ENV=demonstrate nuxt start
             │ └─325840 node /app/node_modules/.bin/nuxt start
             ├─docker-8903c4de66d6f6046176f65d2bcafbfc0a54b106e0f89839e3e7f3efe0cbdc91.scope
             │ ├─3537685 /bin/sh -c mkdir -p /app/logs; if [ -d pre-exec-shells ];then for n in `ls pre-exec-shells/`;do bash pre-exec-shells/$n;done;fi;bash pre_exec.sh;mkdir -p /app/logs/${APP_VERSION}->
             │ └─3537807 /usr/lib/jvm/java-11-openjdk-amd64/bin/java -server -Xmx384m -Xms16m -XX:MetaspaceSize=32m -XX:MaxMetaspaceSize=256m -XX:OnOutOfMemoryError=kill -9 %p -XX:+UnlockExperimentalVMOpt>
             ├─docker-a51f96092c3fa7b61987e1b5a8e1c3c67c3abaae6b4685041e533320f8fa3852.scope
             │ ├─623900 /bin/sh -c /bin/bash -c "cd /app;${CMD_RUNTIME_PREFIX} /app/docker-watchdog ${CMD_RUNTIME_PARAM}"
             │ ├─623952 /bin/bash -c cd /app; /app/docker-watchdog
             │ └─623953 /app/docker-watchdog
             ├─docker-ac512bfea9b13d4ed275609725bee11fa7aad8e14a8b077c4551ec2981b83d63.scope
             │ ├─3543383 /bin/sh -c mkdir -p /var/log/nginx/ && chown -R nginx /var/log/nginx/ && sed -i "s/__WORKER_PROCESSES__/${NGINX_WORKER_PROCESSES:-1}/" /etc/nginx/nginx.conf &&sed -i "s/__WORKER_C>
             │ ├─3543500 nginx: master process nginx -g daemon off;
             │ └─3543502 nginx: worker process
             ├─docker-bde66e65f2ca02ce21a6e177e9857275224b6678d666fa5655a7836c4839d0f0.scope
             │ ├─478014 /bin/sh -c mkdir -p /var/log/nginx/ && chown -R nginx /var/log/nginx/ && sed -i "s/__WORKER_PROCESSES__/${NGINX_WORKER_PROCESSES:-1}/" /etc/nginx/nginx.conf &&sed -i "s/__WORKER_CO>
             │ ├─478116 nginx: master process nginx -g daemon off;
             │ └─478117 nginx: worker process
             ├─docker-c48c87c6fe9bdf05cd121c24bb0123d973024d46f607fe0dd8e89ce1833bb1ac.scope
             │ ├─3639174 /bin/sh -c mkdir -p /app/logs; if [ -d pre-exec-shells ];then for n in `ls pre-exec-shells/`;do bash pre-exec-shells/$n;done;fi;bash pre_exec.sh;mkdir -p /app/logs/${APP_VERSION}->
             │ └─3639261 /usr/lib/jvm/java-11-openjdk-amd64/bin/java -server -Xmx384m -Xms16m -XX:MetaspaceSize=32m -XX:MaxMetaspaceSize=256m -XX:OnOutOfMemoryError=kill -9 %p -XX:+UnlockExperimentalVMOpt>
             ├─docker-e0b51d5bd34295da2a312f82b1b85ec9ff8d142298d6e957a6b23757a91be5d3.scope
             │ ├─2603728 /bin/sh -c mkdir -p /app/logs; if [ -d pre-exec-shells ];then for n in `ls pre-exec-shells/`;do bash pre-exec-shells/$n;done;fi;bash pre_exec.sh;mkdir -p /app/logs/${APP_VERSION}->
             │ └─2603819 /usr/lib/jvm/java-11-openjdk-amd64/bin/java -server -Xmx512m -Xms16m -XX:MetaspaceSize=32m -XX:MaxMetaspaceSize=256m -XX:OnOutOfMemoryError=kill -9 %p -XX:+UnlockExperimentalVMOpt>
             └─docker-fae96ca1eebbdb010e5b2562e27ae980e849e00a3c175ddc1635c5da704de9a8.scope
               ├─3178068 /bin/sh -c mkdir -p /var/log/nginx/ && chown -R nginx /var/log/nginx/ && sed -i "s/__WORKER_PROCESSES__/${NGINX_WORKER_PROCESSES:-1}/" /etc/nginx/nginx.conf &&sed -i "s/__WORKER_C>
               ├─3178156 nginx: master process nginx -g daemon off;
               └─3178158 nginx: worker process

Nov 03 09:37:07 demo-swarm-master-1 systemd[1]: Created slice docker-limit.slice.

4.2.3 docker验证

docker login ccr.ccs.tencentyun.com --username 默认账号 --password 默认密码

4.3 初始化swarm master节点 4.3.1 查看ip信息

ip a

预期返回：

   1: lo:  mtu 65536 qdisc noqueue state UNKNOWN group default qlen 1000
    link/loopback 00:00:00:00:00:00 brd 00:00:00:00:00:00
    inet 127.0.0.1/8 scope host lo
       valid_lft forever preferred_lft forever
	2: ens16:  mtu 1500 qdisc fq_codel state UP group default qlen 1000
    link/ether 00:16:3e:ce:95:32 brd ff:ff:ff:ff:ff:ff
    inet 172.16.2.12/24 brd 172.16.2.255 scope global ens16
       valid_lft forever preferred_lft forever
    inet6 fe80::216:3eff:fece:9532/64 scope link
       valid_lft forever preferred_lft forever
	3: docker0:  mtu 1500 qdisc noqueue state DOWN group default
    link/ether 02:42:75:60:67:74 brd ff:ff:ff:ff:ff:ff
    inet 172.17.0.1/16 brd 172.17.255.255 scope global docker0
       valid_lft forever preferred_lft forever

4.3.2 初始化第一台manager节点

使用机器的内网ip初始化第一台manager节点

docker swarm init --advertise-addr 172.16.3.8

预期返回：

Swarm initialized: current node (73hz6uqcl58v71sn0rsoalsss) is now a manager.

To add a worker to this swarm, run the following command:

    docker swarm join --token SWMTKN-1-sdfdfd-sdfd 172.16.3.8:2377

To add a manager to this swarm, run 'docker swarm join-token manager' and follow the instructions.

4.3.3 获取 master key

docker swarm join-token manager

预期返回：

To add a manager to this swarm, run the following command:

docker swarm join --token SWMTKN-1-1qr56gcrfmq3oh9xv38lpdifk1rbvl37gs1xpisvge7jrh3kpc-ssdfd 172.16.3.8:2377

4.3.4 获取 worker key

docker swarm join-token worker

预期返回：

docker swarm join --token SWMTKN-1-1qr56gcrfmq3oh9xv38lpdifk1rbvl37gs1xpisvge7jrh3kpc-ssss 172.16.3.8:2377

4.4 初始化其它master节点

执行命令（拿mater key）：

docker swarm join --token SWMTKN-1-1qr56gcrfmq3oh9xv38lpdifk1rbvl37gs1xpisvge7jrh3kpc-xxx 172.16.3.8:2377

预期返回：

This node joined a swarm as a manager.

4.5 初始化worker节点

执行命令（拿worker key）：

docker swarm join --token SWMTKN-1-1qr56gcrfmq3oh9xv38lpdifk1rbvl37gs1xpisvge7jrh3kpc-xxx 172.16.3.8:2377

预期返回：

This node joined a swarm as a worker

4.6 按需修改ingress网络

在master1执行：

step1：删除原有ingress网络

docker network rm ingress

step2： 创建新的/16的ingress网络

docker network create --driver overlay --ingress --subnet=10.0.0.0/16 --gateway=10.0.0.1 ingress
