python编程：读取文件动态绘制图形-6_彭世瑜_新浪博客

1. #根据数据文件在窗口中动态路径绘制
2. import turtle
3.
4. def main():
5.     #设置窗口信息
6.     turtle.title('数据驱动的动态路径绘制')
7.     turtle.setup(800, 600, 0, 0)
8.     #设置画笔
9.     pen = turtle.Turtle()
10.     pen.color("red")
11.     pen.width(5)
12.     pen.shape("turtle")
13.     pen.speed(5)
14.     #读取文件
15.     result=[]
16.     file = open("data.txt","r")
17.     for line in file:
18.         result.append(list(map(float, line.split(','))))
19.     print(result)
20.     #动态绘制
21.     for i in range(len(result)):
22.         pen.color((result[i][3],result[i][4],result[i][5]))
23.         pen.forward(result[i][0])
24.         if result[i][1]:
25.             pen.rt(result[i][2])
26.         else:
27.             pen.lt(result[i][2])
28.     pen.goto(0,0)
29.
30.
31. if __name__ == '__main__':
32.     main()

data.txt文件，放在脚本同一路径下即可

300,0,144,1,0,0 300,0,144,0,1,0

300,0,144,0,0,1

300,0,144,1,1,0

300,0,108,0,1,1 184,0,72,1,0,1

184,0,72,0,0,0

184,0,72,0,0,0

184,0,72,0,0,0 184,1,72,1,0,1

184,1,72,0,0,0

184,1,72,0,0,0

184,1,72,0,0,0 184,1,72,0,0,0

184,1,720,0,0,0

原文地址： http://www.icourse163.org/learn/BIT-268001?tid=1002001005#/learn/content?type=detail&id=1002613035&cid=1002856098
